With a super weather-resistant design, the ExplorerLED GOB displays are manufactured with top-quality LED lamps and IC solution, boasting high resolution, more full-color gamut, and viewing angle to reproduce the image vividly.
Pixel Pitch: 1.579mm/ 1.667mm/ 1.875mm/ 1.904mm/ 2mm/ 2.5mm/ 3mm/ 4mm
Get A QuotationGOB is a new kind of packaging technology to solve the problem of LED lamp protection. By coating an advanced transparent epoxy resin on the LED unit board to form effective protection, this material not only has a super high permeability but also has super thermal conductivity.
The GOB LED display can achieve moisture-proof, waterproof, anti-collision, anti-UV, and can be applied to more harsh environments, avoiding large-scale dead lamps, falling lights, and other problems.
You will benefit from the once-and-for all brightness correction in long-term usage of GOB LED display, as we employ flash memory of SPI bus in our newly designed display, which will store the brightness data corrected in manufacturing forever, even after the replacement of moulds.
To ensure no failure of power on important occasions, the Explorerled had adopt easy-plug and replacable power supply to support its GOB LED display. For specific needs, we could equip the display with a backup power supply.
As one of the three factories which possess the GOB technology, we invest a lot to improve its performance with high refresh IC solution, top quality LED chips and our excellent craftsmanship.
After assembly, we will conduct a 72-hours aging test and then cover the surface with epoxy resin coating if all lamps function well. For finished products, we will conduct another aging test for 24 hours.
GOB displays boast 2 times longer working life than regular display screens.
We add the same price on all kinds of LED displays by square meter so it will be cost-effective, especially for bulk purchase and big project.
Its superpower speaks for more applications, which is a good way to expand the market. Its ability of salt spray corrosion resistance enables itself to be widely used in coastal regions.
All of its protective abilities will expand its lifespan, lower possible damage, achieve better performance and more. In other words, it will save money and avoid maintenance troubles.
For example, the lamp beads on the edge will not drop or damage in the event of a strike during transport, installation, or operation. That will liberate you from the trouble of maintenance, and allows you do free and lossless clean as well.
| Technical Specifications | P1.579 | P1.667 | P1.875 | P1.904 | P2 | P2.5 | P3 | P4 |
| Pixel Pitch | 1.579mm | 1.667mm | 1.875mm | 1.904mm | 2mm | 2.5mm | 3mm | 4mm |
| Pixel Configuration | SMD1212 | SMD1010 | SMD1515 | SMD 1515 | SMD1515 | SMD2121 | SMD2121 | SMD2121 |
| Module Size | 240*240mm | 320*160mm | 240*240mm | 320*160mm | 256*128mm | 160*160mm | 192*192mm | 256*128mm |
| Module Resolution | 152*152dots | 192*96dots | 128*128dots | 168*84dots | 128*64dots | 64*64dots | 64*64dots | 64*32dots |
| Pixel Resolution | 401,111dots/m2 | 360,000dots/m2 | 284,444dots/m2 | 275,625dots/m2 | 250,000dots/m2 | 160,000dots/m2 | 111,111dots/m2 | 62,500dots/m2 |
| Cabinet Size | 480*480*85mm | 640*480*85mm | 480*480*85mm | 640*480*85mm | 512*512*85mm | 640*640*85mm | 576*576*85mm | 512*512*85mm |
| Cabinet Weight | 8.0kg | 9.2kg | 8.0kg | 9.2kg | 8.5kg | 12.3kg | 10kg | 8.5kg |
| Average Comfortable Viewing Distance | 2.72m | 2.92m | 3.23m | 3.27m | 3.44m | 4.3m | 5.16m | 6.88m |
| Brightness | 600-800cd/m2 | 600-800cd/m2 | 600-800cd/m2 | 600-800cd/m2 | 600-800cd/m2 | 400-800cd/m2 | 600-800cd/m2 | 500-600cd/m2 |
| View Angle | 160°(W) 120°(H) | 160°(W) 120°(H) | 160°(W) 120°(H) | 160°(W) 120°(H) | 160°(W) 120°(H) | 160°(W) 120°(H) | 160°(W) 120°(H) | 160°(W) 120°(H) |
| Refresh Rate | ≥3，600HZ | ≥3，840HZ | ≥3，840HZ | ≥3，840HZ | ≥3，840HZ | ≥3，200HZ | ≥3，840HZ | ≥3，840HZ |
| Input Voltage | AC110v-220V±10% | AC110v-220V±10% | AC110v-220V±10% | AC110v-220V±10% | AC110v-220V±10% | AC110v-220V±10% | AC110v-220V±10% | AC110v-220V±10% |
| Max.power Consumption | ≤720W/m² | ≤690W/m² | ≤600W/m² | ≤600W/m² | ≤700W/m² | ≤710W/m² | ≤620W/m² | ≤700W/m² |
| Avg. Power Consumption | 240W/m² | 230W/m² | 200W/m² | 200W/m² | 280W/m² | 280W/m² | 260W/m² | 280W/m² |
| Working Temperature | -20°C~+50°C | -20°C~+50°C | -20°C~+50°C | -20°C~+50°C | -20°C~+50°C | -20°C~+50°C | -20°C~+50°C | -20°C~+50°C |
| Storage Temperature | -30°C~+60°C | -30°C~+60°C | -30°C~+60°C | -30°C~+60°C | -30°C~+60°C | -30°C~+60°C | -30°C~+60°C | -30°C~+60°C |
| Working Humidity | 10%-95% | 10%-95% | 10%-95% | 10%-95% | 10%-95% | 10%-75% | 10%-75% | 10%-95% |
| Lifespan | 100,000hours | 100,000hours | 100,000hours | 100,000hours | 100,000hours | 100,000hours | 100,000hours | 100,000hours |
| Maintenance Mode | Front/Rear | Front/Rear | Front/Rear | Front/Rear | Front/Rear | Front/Rear | Front/Rear | Front/Rear |
| Technical Specifications | P1.579 | P1.667 | P1.875 | P1.904 | P2 | P2.5 | P3 | P4 |
| Pixel Pitch | 1.579mm | 1.667mm | 1.875mm | 1.904mm | 2mm | 2.5mm | 3mm | 4mm |
| Pixel Configuration | SMD1212 | SMD1010 | SMD1515 | SMD 1515 | SMD1515 | SMD2121 | SMD2121 | SMD2121 |
| Module Size | 240*240mm | 320*160mm | 240*240mm | 320*160mm | 256*128mm | 160*160mm | 192*192mm | 256*128mm |
| Module Resolution | 152*152dots | 192*96dots | 128*128dots | 168*84dots | 128*64dots | 64*64dots | 64*64dots | 64*32dots |
| Pixel Resolution | 401,111dots/m2 | 360,000dots/m2 | 284,444dots/m2 | 275,625dots/m2 | 250,000dots/m2 | 160,000dots/m2 | 111,111dots/m2 | 62,500dots/m2 |
| Cabinet Size | 480*480*85mm | 640*480*85mm | 480*480*85mm | 640*480*85mm | 512*512*85mm | 640*640*85mm | 576*576*85mm | 512*512*85mm |
| Cabinet Weight | 8.0kg | 9.2kg | 8.0kg | 9.2kg | 8.5kg | 12.3kg | 10kg | 8.5kg |
| Average Comfortable Viewing Distance | 2.72m | 2.92m | 3.23m | 3.27m | 3.44m | 4.3m | 5.16m | 6.88m |
| Brightness | 600-800cd/m2 | 600-800cd/m2 | 600-800cd/m2 | 600-800cd/m2 | 600-800cd/m2 | 400-800cd/m2 | 600-800cd/m2 | 500-600cd/m2 |
| View Angle | 160°(W) 120°(H) | 160°(W) 120°(H) | 160°(W) 120°(H) | 160°(W) 120°(H) | 160°(W) 120°(H) | 160°(W) 120°(H) | 160°(W) 120°(H) | 160°(W) 120°(H) |
| Refresh Rate | ≥3，600HZ | ≥3，840HZ | ≥3，840HZ | ≥3，840HZ | ≥3，840HZ | ≥3，200HZ | ≥3，840HZ | ≥3，840HZ |
| Input Voltage | AC110v-220V±10% | AC110v-220V±10% | AC110v-220V±10% | AC110v-220V±10% | AC110v-220V±10% | AC110v-220V±10% | AC110v-220V±10% | AC110v-220V±10% |
| Max.power Consumption | ≤720W/m² | ≤690W/m² | ≤600W/m² | ≤600W/m² | ≤700W/m² | ≤710W/m² | ≤620W/m² | ≤700W/m² |
| Avg. Power Consumption | 240W/m² | 230W/m² | 200W/m² | 200W/m² | 280W/m² | 280W/m² | 260W/m² | 280W/m² |
| Working Temperature | -20°C~+50°C | -20°C~+50°C | -20°C~+50°C | -20°C~+50°C | -20°C~+50°C | -20°C~+50°C | -20°C~+50°C | -20°C~+50°C |
| Storage Temperature | -30°C~+60°C | -30°C~+60°C | -30°C~+60°C | -30°C~+60°C | -30°C~+60°C | -30°C~+60°C | -30°C~+60°C | -30°C~+60°C |
| Working Humidity | 10%-95% | 10%-95% | 10%-95% | 10%-95% | 10%-95% | 10%-75% | 10%-75% | 10%-95% |
| Lifespan | 100,000hours | 100,000hours | 100,000hours | 100,000hours | 100,000hours | 100,000hours | 100,000hours | 100,000hours |
| Maintenance Mode | Front/Rear | Front/Rear | Front/Rear | Front/Rear | Front/Rear | Front/Rear | Front/Rear | Front/Rear |
